Description
Specifications
Media

Description

Sorting and appraisal of grain

  • Determination of the full barley proportion
  • Tiltable sieve stack and sieve cleaning
  • Available with 3, 4 or 5 sieves
  • Robust and solid construction
  • Official method in accordance with MEBAK, EBC and ICC



Usage area
The Sortimat is designed for sorting and classifying agricultural grain crops and products derived from them. The main focus of use is in the boldness determination of brewing barley. The Sortimat can be used to appraise the productive capacity of grain, legumes, oil seeds and pellets.



Function
The Sortimat is designed for a sample quantity of 100 g. The tiltable stack of sieves and the integrated sieve cleaning make it possible to carry out several samples within a minimal amount of time. Complicated dismantling and cleaning after every sorting. The laboratory sorting machine is available in three variants with three, four or five sieves. The Sortimat consists of a mechanical vibrating device with an electric motor and an electronic timer for controlling the sieving time.



Accessories
Separating device for wheat or for barley and rye: These plastic channels with milled recesses sort broken and round grain from the sample. They are inserted into the filling opening and held in place with a mounting bracket. A double tray is available for sorting malt. The sieves are exchangeable.

Specifications

Technical Data

Product K3
Voltage 3 230 V, 50 Hz
Output 40 VA
Dimensions 550x270x350 mm
Weight 28 kg
Item Number 1240 0100



Product K4
Voltage 4 230 V, 50 Hz
Output 40 VA
Dimensions 550x270x380 mm
Weight 29 kg
Item Number 1240 0110



Product K5
Voltage 5 230 V, 50 Hz
Output 40 VA
Dimensions 550x270x410 mm
Weight 30 kg
Item Number 1240 0120



Accessories Item Number
Broken and round grain separating device for wheat 2440 0021
Broken and round grain separating device for barley and rye 2440 0020
Clamp for separating device 3175 2410
Collection tray for malt 2440 0022
Various sieves made from brass or stainless steel (round or elongated hole) By request
